Forscan for 2022

Avslash

Tremor Fan
Joined
Oct 20, 2021
Messages
33
Reaction Points
84
Location
The Lonestar State
Current Ride
2022 KR Tremor
Well, I hooked up for the first time to my 2022 7.3L. and made some changes in plain english mode.

I succeeded in enabling Bambi mode, and getting rid of the double honk on exiting the vehicle when running.

I was not able to get the trans and coolant temp to display digitally above the gauges. Anyone have any pointers regarding those items? The closest listings I could find in plain english were "Engine Coolant Temperature Gauge" and "Transmission Temperature Gauge". I changed both of those setting to "enabled", but nothing changed on the display so I reverted them back to the factory settings.

Any insight would be appreciated.


Modman

Founding Member
Joined
Jun 25, 2021
Messages
1,148
Reaction Points
3,399
Location
SE Michigan
Current Ride
2022 F250 Star White Lariat Ultimate
Well, I hooked up for the first time to my 2022 7.3L. and made some changes in plain english mode.

I succeeded in enabling Bambi mode, and getting rid of the double honk on exiting the vehicle when running.

I was not able to get the trans and coolant temp to display digitally above the gauges. Anyone have any pointers regarding those items? The closest listings I could find in plain english were "Engine Coolant Temperature Gauge" and "Transmission Temperature Gauge". I changed both of those setting to "enabled", but nothing changed on the display so I reverted them back to the factory settings.

Any insight would be appreciated.
@Avslash here is the advice I provided yesterday:

@TX Crawler Look back at page 7... Posts #124-136. Let me know if you have any questions - would be happy to assist.


Avslash

Tremor Fan
Joined
Oct 20, 2021
Messages
33
Reaction Points
84
Location
The Lonestar State
Current Ride
2022 KR Tremor
@Avslash here is the advice I provided yesterday:

Thanks @Modman

So my truck is a 7.3L.

Looking at the motorcraft website you linked in the earlier post, my factory as built string is as follows:

720-07-01 8409 0AA0 086E

So am I correct in assuming that it should be changed to the following for non-turbo 7.3L, with trailer brake controller, with power running boards:

720-07-01 8409 0A50 086E

Thanks for the assist. It has been a LONG time since I had to do any hex, so I'm a bit nervous.


Modman

Founding Member
Joined
Jun 25, 2021
Messages
1,148
Reaction Points
3,399
Location
SE Michigan
Current Ride
2022 F250 Star White Lariat Ultimate
Your new string will be:

720-07-01 8409 0A50 081E

The last two digits are the checksum. Technically you don't have to change this but you will get a "checksum" error if you don't. It will recalculate for you but some don't like seeing the error.


Willie

Tremor Fanatic
Joined
Apr 13, 2021
Messages
104
Reaction Points
370
Location
Texas
Current Ride
2000 F-250 Diesel
How did you get the readouts above the gauges to work? I went into IPC and enabled both "Engine Temp Gauge" and Transmission Temp Guage" but thatdidn't do it....
Sorry for the late response. I've been away from my computer. I selected "IPC", went to Address 720-07-01 and changed my second instruction from '0EA0' to '0A50'. Hope that helps!


Joe_Lee

Tremor Fanatic
Joined
Sep 3, 2021
Messages
115
Reaction Points
311
Location
Spanish Fort, AL
Current Ride
2022 F350 King Ranch Ultimate Tremor 6.7 Diesel Star White / Stone Gray
So, the only way to enable the numbers over the temp gauge is to do it as described above in the AS BUILT code and that removes the boost gauge and replaces it with the transmission temp?

I did that successfully but I could not find my boost gauge, even in the menu so I reverted back to factory and tried the plain English route but enabling “engine temp gauge” did not work.


Modman

Founding Member
Joined
Jun 25, 2021
Messages
1,148
Reaction Points
3,399
Location
SE Michigan
Current Ride
2022 F250 Star White Lariat Ultimate
@Joe_Lee you only want to change one character in the address (the one indicated by the *)

720-07-01 xxxx xx*x xx--

Changing to a "5" will turn the engine and trans temp digital gages on.

Edit: changing the character previous to this will have other consequences. For instance if you have an "E" and change to an "A" you will turn off the boost gauge. There are other settings too depending on what features you have on your truck. So, don't use any of the full strings I listed for others above unless they are applicable to your truck as well. Happy to give you the correct new string if you provide your As-Built data...

Hopefully this makes sense - props to @coreyms for pointing this out. After I reread my original post it was assuming features so I updated accordingly.

Last edited:

Joe_Lee

Tremor Fanatic
Joined
Sep 3, 2021
Messages
115
Reaction Points
311
Location
Spanish Fort, AL
Current Ride
2022 F350 King Ranch Ultimate Tremor 6.7 Diesel Star White / Stone Gray
@Joe_Lee you only want to change one character in the address (the one indicated by the *)

720-07-01 xxxx xx*x xx--

Changing to a "5" will turn the engine and trans temp digital gages on. If you also change the character prior to that to an "A" you will turn the turbo boost off - this is for gas trucks, diesel should remain with an "E"
ok got it, thanks!


Modman

Founding Member
Joined
Jun 25, 2021
Messages
1,148
Reaction Points
3,399
Location
SE Michigan
Current Ride
2022 F250 Star White Lariat Ultimate
Has anyone enabled the ability to use the Nav while driving?

From what I gather, this is accomplished by changing the country code in APIM and it looks like the location of the memory address has changed for 22MY/Sync4.

From my vehicle:

7D0-03-01 5553 0203 038B

55 = U
53 = S

My question is - what do you change it to and are there any other effects?? I have read about the red circle around the speed limit, curious if there is anything else?


Modman

Founding Member
Joined
Jun 25, 2021
Messages
1,148
Reaction Points
3,399
Location
SE Michigan
Current Ride
2022 F250 Star White Lariat Ultimate
Ok I think I have it. I found an explanation I am reasonably satisfied with on the XDA forum (post#209):


It is in the first two digits of the country code. US = "5553"

55 = 01010101
57 = 01010111

That second to last bit (value of 2 in hex) turns it on or off.

So to enable the feature change "5553" to "5753" in the APIM As-Built 7D0-03-01 (for US vehicles)


Avslash

Tremor Fan
Joined
Oct 20, 2021
Messages
33
Reaction Points
84
Location
The Lonestar State
Current Ride
2022 KR Tremor
Your new string will be:

720-07-01 8409 0A50 081E

The last two digits are the checksum. Technically you don't have to change this but you will get a "checksum" error if you don't. It will recalculate for you but some don't like seeing the error.
Thanks @Modman

Worked like a charm.


Joe_Lee

Tremor Fanatic
Joined
Sep 3, 2021
Messages
115
Reaction Points
311
Location
Spanish Fort, AL
Current Ride
2022 F350 King Ranch Ultimate Tremor 6.7 Diesel Star White / Stone Gray
@Joe_Lee you only want to change one character in the address (the one indicated by the *)

720-07-01 xxxx xx*x xx--

Changing to a "5" will turn the engine and trans temp digital gages on.

Edit: changing the character previous to this will have other consequences. For instance if you have an "E" and change to an "A" you will turn off the boost gauge. There are other settings too depending on what features you have on your truck. So, don't use any of the full strings I listed for others above unless they are applicable to your truck as well. Happy to give you the correct new string if you provide your As-Built data...

Hopefully this makes sense - props to @coreyms for pointing this out. After I reread my original post it was assuming features so I updated accordingly.
My as built, via the link and using my vin is:
720-07-01 8409 0EA0 0B75


720-07-01
84090EA00B75

I want to keep my boost guage but put the temp numbers over the engine temp guage.

Thank you

Last edited:

Modman

Founding Member
Joined
Jun 25, 2021
Messages
1,148
Reaction Points
3,399
Location
SE Michigan
Current Ride
2022 F250 Star White Lariat Ultimate
My as built, via the link and using my vin is:
720-07-01 8401 0EA0 0B6D
Your new string will be 720-07-01 8401 0E50 0B1D

It will end up looking similar to this for the temps (I stole your pic @Utah Tremor ). I can't speak to the DEF part since I do not have a diesel.



Joe_Lee

Tremor Fanatic
Joined
Sep 3, 2021
Messages
115
Reaction Points
311
Location
Spanish Fort, AL
Current Ride
2022 F350 King Ranch Ultimate Tremor 6.7 Diesel Star White / Stone Gray

Joe_Lee

Tremor Fanatic
Joined
Sep 3, 2021
Messages
115
Reaction Points
311
Location
Spanish Fort, AL
Current Ride
2022 F350 King Ranch Ultimate Tremor 6.7 Diesel Star White / Stone Gray
Your new string will be 720-07-01 8401 0E50 0B1D

It will end up looking similar to this for the temps (I stole your pic @Utah Tremor ). I can't speak to the DEF part since I do not have a diesel.

View attachment 39153
After I used the string you provided - which seems to have worked fine - I noticed I had typed in my as built data wrong in my previous reply.

The correct string from factory was:

720-07-01 8409 0EA0 0B75

Is the string you provided still correct or will I need to change it?

To clarify, I entered what you provided as:

0E50 0B1D


Modman

Founding Member
Joined
Jun 25, 2021
Messages
1,148
Reaction Points
3,399
Location
SE Michigan
Current Ride
2022 F250 Star White Lariat Ultimate
You should be fine... The last two characters are a checksum and will be automatically calculated.

The correct string would be 0E50 0B25. If you go back in and look it should be listed that way now in that memory address.
